Boilers
Still Spirits Create+ Boiler 25L (NZ/AU)
​
The Create+ Boiler 25 L is the recommended boiler base for use with the Create+ T500 Column & Condenser and the Create+ Alembic Copper Dome & Condenser. With a maximum capacity of 25 litres, the Boiler 25 L is designed for distillers seeking precise control and versatile functionality. It features dual element control switches to provide more control during distillation. The Boiler 25 L comes complete with a 2" tri-clamp to DN40 threaded adapter, allowing for connection to 2" tri-clamp accessories, so your customers can experiment with different setups and attachments.
​
Key Features:
​
- Dual element control switches provide more control during distillation - when both switches are in the ON position, the element will be supplied full power of 2200W (1600 if using a US/CA unit). When one switch is in the OFF position, it will only consume 1100W (or 1100W/500W if using a US/CA unit) of power.
​
-
- Designed in New Zealand
-
- Boil dry reset
-
- Thermal cut out fuse
-
- Waste discharge tap with a stainless-steel ball valve
-
- Boiler lid with 48 mm opening
-
- 25 L Boiler capacity
-
- Connects to 2" tri-clamp distilling accessories
-
- 304 grade stainless steel construction
-
- High temperature resistant food grade silicone
DISCLAIMER: Please note that in certain countries alcohol distillation and the possession of distilling equipment is illegal and permits/licenses may be required. For guidance or advice, contact your relevant local authorities.
​
What's Included
​
Create+ Boiler 25 L
Create+ Boiler Lid
2" Tri-clamp to DN40 Threaded Adapter (includes: Silicon gasket and DN40 Nut)
​
​
Beer Me Boiler 30 Litres
35L DigiBoil - Digital Turbo Boiler 2400watt
$229.00
​​
-
Liters and Gallon Graduations
-
Stainless steel tap with barb and 1/2 thread
-
Dual element control (so you can adjust the power from 500watts, 1900watts or 2400watts)
-
Compatible with the reflux and pot still that we sell (NOTE: when using our pot or reflux stills do not use more than 1900watts)
-
Easy to use
-
Great for use as a hot liquor tank, boiler, or hot water urn
-
Great for all grain boil in bag
-
Concealed element for easy cleaning
-
Can also be used for sous vide cooking
Want to save some power?
You can also purchase the neoprene jacket/parka that fits this unit . This will reduce your heat loss by about 200-300 watts.
This digital turbo boiler is a quality made 304 grade stainless steel turbo boiler.
​
The 35Liter size is the total rated size brimful, so typically if you are using this as a beer boiler you would probably only fill it up to 25-30L so you had 5-10 litres of head space to boil comfortably.
​
The boiler has a quality made stainless tap with stainless barb and 1/2inch thread so you can attach the wide range of other half inch fittings such as camlocks and many other fittings that we can supply.
​
The unit comes with a concealed element for easy cleaning.
​
The digital display can be set from 0C and up to 140C with 1C increments and 1C resolution on the display.
The side of the boiler is pre-marked with graduations in litres and gallons that are accurate to +/- 1 liter. 220-240v option is 2400 watts
65L DigiBoil - Digital Turbo Boiler 3300 Watt
$369.00
​
Liters and Gallon Graduations
* Stainless steel tap with barb and 1/2 thread
* Triple element control (so you can adjust the power from 500watts, 1900watts or 2400watts)
* Compatible with the reflux and pot still (NOTE: when using the pot or reflux stills do not use more than 1900watts)
* Easy to use
* Great for use as a hot liquor tank, boiler, or hot water urn
​
* Great for all grain boil in bag
* Concealed element for easy cleaning
​
* Can also be used for sous vide cooking
Want to save some power?
​
220-240v option is 2400watts
This digital turbo boiler is a quality made 304 grade stainless steel turbo boiler.
​
The 65Liter size is the total rated size brimful, so typically if you are using this as a beer boiler you would probably only fill it up to 50-60L so you had 5-10 litres of head space to boil comfortably.
​
The boiler has a quality made stainless tap with stainless barb and 1/2inch thread so you can attach the wide range of other half inch fittings such as camlocks and many other fittings that we can supply.
​
The unit comes with a concealed element for easy cleaning.
​
The digital display can be set from 0C and up to 140C with 1C increments and 1C resolution on the display.
​
The side of the boiler is pre-marked with graduations in litres and gallons that are accurate to +/- 1 liter.
​
The size of this unit is:
42cm Diameter
74cm high
​
Q. Can I use this on a standard 10amp power socket in my house?
A. Out of the box this unit needs to be manufactured with a 15amp power socket. With that said you can conver this to a 10amp compatible device in two different ways. You can either:
1. Purchase a device like this Ampfibian Mini 15amp to 10amp adaptor. If you do this you will be able to run the Digiboil however if you turn on all three elements you will trip the circuit breaker. For this reason you will only be able to use a maximum of 2 of the elements. (not all three)
2. Alternatively you can remove the cord and replace the cord on this device with a 10amp cord but if you do this you need to also disconnect the larger element so this is disabled in the unit.
So yes you can run this device on a 10amp power socket however only if you are happy to have 1300watts less power as a result.
